Product ID: | XNT-TF-XG185H |
product name: | microSD clamshell type 1.85 high |
specification: | Plastic: black high temperature UL94V-0; terminal: copper alloy; shell: stainless steel; |
Product Note: | Micro SD flip cover L13.50*W13.30*H1.85 same as molex50091-08xx |
Product Category: | microSD TF SD Series |
Technical parameters:
1. Rated current: 0.5mA AC/DC
2. Rated voltage: 100V AC/DC
3. Operating temperature: -25°C ~ +85°C
4. Storage temperature: -40°C ~ +85°C
5. Contact resistance :50m ohms max.
6. Insulation resistance: 1000M ohms min./500VDC
7. Durability: 10000 times
8. Product temperature resistance: 260±5°C 10S
9. RoHS Compliant
:
1. This connector is widely used in mobile phones. , Tablet PCs, navigators, LCD TVs, automobiles, smart wearable devices, aeronautics, etc.;
2. Secondary product inspection processes are: IQC feed inspection -> storage -> pre-line self-test -> IPQC inspection - -> FQC final inspection -> OQC cargo inspection
3. This product production process is: pre-line inspection -> molding cutting tape -> assembly slider, tie rod, spring -> assembly shell -> push test --> Electrical test --> Flatness test --> Appearance test --> FQC test --> Storage
